The Five-Brush Automatic That Cleans Like A Tunnel

It’s no secret – in order to attract repeat business, an In-Bay car wash must feel inviting. That’s why the FreeStyler® soft-touch automatic is designed from “the top down” to offer an open, airy, and pleasant wash experience we call ClearBay®. While floor-mounted rollovers can feel claustrophobic, the FreeStyler® is different. Its overhead gantry design opens up the wash bay, speeds up loading, and increases throughput.

Once each vehicle is loaded, the effective five-brush system delivers a thorough clean, and unsurpassed throughput among soft-touch in-bays.

The available HydroBlade® with Wheel Stinger® provides multiple revenue generators in one exciting package. The HydroBlade® surrounds the vehicle with 1 high pressure that blast dirt out of 'nooks and crannies,' creating a soft-touch/high-pressure 'combination wash' customers will gladly pay more for. Included with the HydroBlade®, the Wheel Stinger® delivers focused wheel cleaning with high-pressure nozzles and on-board Chemical Tire Applicators (CTAs).

The Easy Choice For Customers

The unique overhead gantry design of the FreeStyler® has another benefit, too. It keeps the wash gear up and away from dirt and water – preventing the grit and ice related failures that plague floor-mounted rollovers.

To maximize reliability and savings, Variable Frequency Drive motors provide soft starts, delivering prolonged equipment life and reduced peak energy costs. Rugged motor-and-gearbox units are epoxy coated, and floating mounts minimize bearing loads, extending component life.

For peace of mind, all wash wheels simply push out of the way in the case of an accidental drive-off, eliminating potential vehicle and equipment damage. The patented pivoting top wheel floats out of harm's way, avoiding possible damage associated with competitors' guillotine-style top wheels. What's more, the optional Whisper Wheel® top wheel fill runs quietly, increasing customer perception of a thorough, yet gentle wash process.

Sample FreeStyler® In-Bay Automatic Wash Bay

FreeStyler Rendering
Equipment Shown:
  • Bay Length: 45'
  • Bay Height: 11'8"
  • Bay Width: 16'6"
Physical Building Requirements:
  • Minimum Bay Length: 32' *
  • Minimum Bay Height: 11'8" *
  • Minimum Bay Width: 14'9" *

*Recommended Minimum size without Dryers.

With the FreeStyler®, Wash Cars Your Way.


  • FreeStyler
  • Entrance Sign
  • In-Bay Sign
  • Undercarriage
  • 30HP Air Cannon Dryer System


  • Wheel Stinger® and Onboard CTA
  • HydroBlade® with Wheel Stinger® and Onboard CTA
  • Triple Foam
  • Sealer Wax
  • Drying Agent
  • Bug Spray (with floor-mounted manifold)
  • Onboard & Freestanding Vehicle Dryers
  • DuraShiner® CF tire shiner

Designed With Operators In Mind

The FreeStyler is constructed with many standard features that will keep you up and running, while also cutting operational expenses. One such feature is the FreeStyler’s sturdy reduced-weight aluminum carriage construction. This design not only is corrosion free for unrivaled longevity, but it also greatly reduces utility load usage which decreases operating expenses.

•Floating Gearboxes which significantly extend the life of gearbox bearings and internal components by minimizing radial and axial bearing loads typical of rigid-mounted gearboxes.

•Sealed Aluminum, Direct Drive Wheel & Carriage Drive Motors are maintenance free and utilize wet atmosphere design to eliminate water induced electrical failure and deliver trouble free long life.

•Grease For Life Bearings on all pivot and drive bearings are automotive grade, requiring less maintenance and reduces operating costs.

•A Single Shaft Carriage Drive means all overhead carriage travel wheels operate on a common shaft which significantly minimizes maintenance and expenses.

A great system just keeps getting better. With the FreeStyler minimal backroom space is required for installation. This is because the FreeStyler has most controls and mixing valves self-contained on-board. Operators can quickly access the uniquely concealed onboard components through the side and back panels, or make fast and easy finger-tip adjustments to the equipment from easy to reach onboard carriage controls.

This onboard equipment room feature can not only provide big saves on new wash construction costs, but also when retrofitting into existing in-bay sites.

All FreeStyler wash systems exclusively use Neo-Tex ‘foam’ vehicle wash material. Neo-Tex is a closed cell material that has spongy physical characteristics but since it is closed cell, it does not absorb water and dirt does not penetrate into it; easily maintaining that “like new” appearance.

Neo-Tex is approximately 4 times lighter than traditional cloth wash material. Lighter material and lighter operation translate to less wear and tear on wash machinery.

Unlike cloth that is very strong, Neo-Tex is more forgiving and individual strands will actually break if it becomes caught or tangled in anything during the wash process. This greatly minimizes potential vehicle damage to antennas, mirrors, and other aftermarket accessories, and provides an exceptionally gentle wash experience.

The FreeStyler is available in three distinctive branding enhancement packages that enable you to customize the exterior appearance of your FreeStyler to correspond with your facility’s branding needs.

  • BaseFreeStyler
  • Stylerto Go FreeStyler
  • Premium StylerFreeStyler

Choose from items such as carriage finish, wash media colors, branding panel color, and custom decal options to make it your own.

The Easy Choice For Customers.

The powerful five-brush FreeStyler system cleans everything it touches, providing a quick, complete wash –with throughput of up to 20 happy customers per hour, every hour it operates.

Its five smooth contouring wash wheels gently hug vehicles, delivering consistently safe wheel pressure, regardless of vehicle size, for notably cleaner results.

And for the ultimate in system safety, all FreeStyler wash wheels are specifically engineered with a pivoting design which means they glide gracefully out of the way should a customer accidentally drive off during the wash cycle. This feature not only eliminates potential damage to wash equipment, but also to customers’ vehicles.

The unique overhead gantry design of the FreeStyler has another benefit too. It keeps the wash gear up and away from dirt and water –preventing the grit and ice related failures that plague other rollovers.

All of which means the FreeStyler’s overhead design:

  • Delivers maximum uptime and reliability
  • Provides smooth operation for a more enjoyable wash experience
  • Produces fast wash performance
  • Reduces load torque on motors
  • Decreases maintenance requirements
